Steel Emergency Lights

Steel Emergency Lights

Steel emergency lights are rugged, UL 924 compliant fixtures engineered for high-abuse applications. Each metal emergency light uses a tamper-resistant 18- or 20-gauge steel housing that delivers superior durability, fire resistance, and vandal protection—ideal for stairwells, schools, correctional facilities, and mechanical rooms. Explore the broader category of commercial emergency lights for additional styles and ratings.

UL 924 LED Lamp Heads 90-Min Backup Wall & Ceiling Mount Tamper-Resistant Self-Testing
Buyers Guide Tips

What to Look for in Steel Emergency Lights

  • Housing construction: 18/20-gauge steel, powder-coat finish, vandal-resistant hardware; consider tamper-proof fasteners.
  • Egress performance: UL 924 listing with verified 90-minute emergency runtime and compliant photometrics.
  • Lamp heads & optics: Adjustable LED heads; choose lumen package/beam to meet corridor and stair spacing targets.
  • Mounting & power: Wall or ceiling mounting with dual 120/277 VAC input; confirm projection and clearances.
  • Environment rating: Specify damp/wet or enclosure (NEMA/IP) for moisture, wash-down, or corrosive areas if required.
  • Diagnostics: Self-testing availability to automate monthly 30-second and annual 90-minute checks with clear status indicators.
  • Serviceability: Favor quick-connect batteries and accessible push-to-test; design for floor-visible status to ease inspections.

These fixtures excel in warehouses, utility corridors, stair towers, and educational facilities where thermoplastic units may fail. Powder-coated steel enclosures resist impact, heat, tampering, and moisture for long service life in demanding environments.

Every model includes a built-in battery system that delivers at least 90 minutes of egress illumination during outages. All steel emergency lights are tested to UL 924 and meet NFPA 101 and OSHA life-safety requirements. For automated maintenance, choose self-testing emergency lights; for sealed, washdown, or corrosive areas, compare NEMA-rated emergency lights; and for outdoor or damp interiors, browse wet-location emergency lights.

💡 What is a steel emergency light?
A commercial-grade emergency lighting unit built with a tamper-resistant steel housing—providing bright egress illumination, 90-minute battery backup, and unmatched durability for harsh or high-traffic environments.

Filter products

Match all

Related Categories

Clear all

10 Products

Steel Emergency Lights – Spec Guide

  • Compliance & runtime: UL 924 listed with a minimum 90-minute emergency duration; coordinate with NFPA 101 / AHJ requirements for egress levels and spacing.
  • Housing construction: 18- or 20-gauge steel enclosure, powder-coat finish, reinforced seams, and tamper-resistant fasteners; consider vandal-resistant lens shields in public areas.
  • Lamp heads & optics: Adjustable LED heads; specify lumen package and beam (spot/flood) to meet corridor/stair foot-candle and spacing targets at the planned mounting height.
  • Environment rating: Select damp/wet or enclosure ratings (e.g., NEMA / IP) for humidity, wash-down, or corrosive atmospheres; use gasketed entries and sealed hardware where required.
  • Power & charging: Dual 120/277 VAC input, solid-state charger, automatic transfer, brownout protection, low-voltage disconnect, and surge suppression for long-term reliability.
  • Battery chemistry: Maintenance-free Ni-Cd or lithium; verify recharge time, ambient temperature range, expected service life, and availability of cold-weather heater kits if needed.
  • Remote capacity (optional): If remote-capable, confirm available watts/voltage after onboard load to power remote heads for the full 90-minute duration; check run length and voltage drop limits.
  • Mounting & clearances: Wall/ceiling mounting with universal backplate/knockouts; confirm projection, headroom, conduit access, and separation from sprinklers/detectors/signage; preserve push-to-test access post-install.
  • Diagnostics: Self-testing option to automate monthly 30-second and annual 90-minute tests; status/fault indicators should be visible from floor level for quick inspections.
  • Corrosion & durability: Specify powder-coat system, stainless hardware, and sealed conduit hubs for coastal/industrial sites; consider impact ratings for high-abuse locations.
  • Serviceability: Favor hinged doors or captive screws, quick-connect batteries, labeled terminals, and front-accessible test/reset to minimize downtime during PM.

Additional Resources

FAQs About Steel Emergency Lights

Why choose steel over thermoplastic?

Steel emergency lights feature heavy-duty enclosures that offer superior impact resistance, tamper protection, and long-term durability. These metal emergency lights are ideal for high-abuse environments like factories, correctional facilities, stairwells, and mechanical spaces.

Are steel emergency lights code compliant?

Yes. Most LED steel emergency lights are UL 924 listed and meet NFPA 101 and OSHA standards, delivering at least 90 minutes of battery-powered illumination during emergencies.

Do they include battery backup?

All steel emergency lighting units include internal battery systems that activate automatically during power loss—ensuring uninterrupted egress lighting and full code compliance.

Can I use these in wet or damp areas?

Yes. Many steel emergency lights are rated for wet locations or damp environments. Always confirm the IP or NEMA rating for your installation setting.

Are self-testing models available?

Absolutely. Many models feature self-testing diagnostics that run automatic monthly and annual code-required function checks—reducing the need for manual inspections.

Where are steel emergency lights typically used?

Steel emergency lights are common in industrial plants, warehouses, stairwells, mechanical rooms, and utility corridors—anywhere requiring enhanced durability and consistent egress lighting performance.
