Die-Cast Aluminum Exit Signs

Metal-framed LED EXIT signs with crisp 6" letters, field-selectable chevrons, and 90-minute battery backup—built for high-traffic interiors that demand a clean, architectural look. Browse all exit signs or see integrated exit sign & emergency light combos for doorways and intersections.

Browse Related: Die-Cast Aluminum Emergency Lights

UL 924 Cast-Aluminum Frame LED Legend 90-Min Backup
Buyers Guide Tips
  • Face & arrows: Choose single-face for one-way corridors; double-face for intersections. Apply field chevrons (none/left/right/double) using the included template for perfect alignment.
  • Finish & fit: Cast-aluminum housings resist flex and scuffs; pick white, black, or brushed aluminum to match interiors. Low-profile canopies keep installs tight to the surface.
  • Power & testing: Dual-voltage 120/277 VAC with push-to-test and status LED is standard; add self-diagnostics (SDT) to automate monthly/annual checks.
  • Environment: Use damp-location by default; select wet-location/IP/NEMA versions for exterior canopies, garages, or wash-down areas; cold-weather kits where required.
  • Letter color: Red or green LEDs are common; verify local preferences or city rules before submittal (NYC/Chicago models differ).
What are die-cast aluminum exit signs? Rigid, metal-framed LED EXIT signs that pair architectural styling with durable housings and code-required battery backup for egress.

Need a city-specific model? See NYC-approved exit signs and Chicago-approved exit signs for local requirements.

Planning for exposure? Compare wet-location exit signs for outdoor or wash-down areas.

Prefer an ultra-slim look? Explore edge-lit exit signs for low-profile, floating legends.

Die-Cast Aluminum Exit Signs Collection
Trust & Policies

Filters

Related Categories

Clear all

8 Products

Die-Cast Aluminum Exit Signs - metal frame, LED legend, 90-min - Features & Specs

  • Housing / finish: Cast-aluminum chassis with powder-coat finish (white/black/aluminum); optional tamper-resistant hardware for public areas.
  • Legend & illumination: Uniform LED letters (typ. 6" / 3⁄4" stroke) with high contrast; edge-lit and panel styles available; viewing-distance classes common (50/75/100 ft).
  • Electrical: 120/277 VAC input, solid-state charger, status LED, push-to-test; options for dual-circuit AC or special voltages (SPV 208/220/240 VAC).
  • Runtime / diagnostics: UL 924 90-minute battery backup standard; self-diagnostics (SDT) automates monthly (~30 s) and annual (90-min) tests with fault indication.
  • Faces & arrows: Single- or double-face configurable; field-applied chevrons (none/left/right/double) with alignment template for clean, code-visible direction.
  • Environment: Damp-location as standard; select wet-location/IP/NEMA units or cold-weather kits for exterior/freezer use.
  • Compliance: UL 924 listed for egress; city-approved variants available (NYC 8" red letters; Chicago requirements differ by model—see city pages).

FAQs About Die-Cast Aluminum Exit Signs

Do die-cast frames actually survive “heavy-duty” use without looking beat up?

Yes. Cast-aluminum housings are rigid and impact-resistant, so they won’t flex or crack like basic plastic. They hold alignment, hide scuffs better, and keep a clean architectural profile in high-traffic areas. For extreme abuse (detention/industrial), some sites step up to steel—die-cast balances durability with design.

Will the metal housing complicate ceiling or end mounting above doors?

No. Die-cast units ship with low-profile universal canopies for wall, ceiling (top), or end mounting on standard J-boxes. Despite the metal frame, installed depth stays slim and clear of door swing.

How should I pick letter color and face count for design-sensitive areas?

Use red or green to match local expectations and interior contrast (verify NYC/Chicago rules if applicable). Single-face works for one-way corridors; choose double-face at intersections or open areas to reduce fixture count while maintaining sightlines.

Any install tips to keep the face perfectly aligned and arrows clean?

Square the canopy to corridor lines before tightening, then apply chevrons with the alignment template after the face is seated. A quick wipe prevents fingerprints on brushed or black finishes.

When should I choose wet-location or cold-weather versions?

Use wet-location/IP/NEMA models for exterior canopies, garages, or wash-down zones, and add cold-weather kits for low-ambient/freezer applications so legend brightness and battery runtime remain reliable.
